Description
Specification
* Desktop Mailing Label Printer jst2250
* Print Method: Thermal Transfer / Direct Thermal
* Resolution: 203 dpi (8 dots/mm)
* Print Speed: 7IPS (177 mm/s)
* Print Width: 4.09″ (104mm)
* Print Length: Min. 0.16” (4 mm); Max. 100” (2540 mm)
* Memory: 8MB Flash (4MB for user storage) / 16MB SDRAM
Sensor Type
Adjustable reflective sensor and transmissive sensor, left aligned
Media
* Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
* Width: 1” (25.4 mm) Min. – 4.64” (118 mm) Max.
* Thickness: 0.003” (0.06 mm) Min. – 0.01” (0.25 mm) Max.
* Label roll diameter: Max. 8” (203.2 mm) , Max. 6” (152.4 mm)
* Core diameter: 3”, 1.5” (76,2 mm, 38,1 mm)
Ribbon
* Types: Wax, wax/resin, resin
* Length: 1471’ (450 m)
* Width: 1.18” Min – 4.33” (30 mm – 110 mm) Max
* Ribbon roll diameter.: 2.99“ (76 mm)
* Core diameter: 1” (25.4 mm)
Printer Language
EZPL , GEPL, GZPL auto switch
Software
* Label design software: GoLabel (for EZPL only)
* Driver & DLL: Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008
Resident Fonts
* Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
* Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
* Bitmap fonts 8 times expandable in horizontal and vertical directions
* Scalable fonts 90°, 180°, 270° rotatable
Download Fonts
* Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
* Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable
Barcodes
* 1-D Bar codes:
Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128, UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal Code, RPS 128 and GS1 DataBar
* 2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code
Code Pages
* CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
* WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
* Unicode (UTF8, UTF16)
Graphics
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software
Interfaces
* Serial port: RS-232 (DB-9)
* USB 2.0
* Ethernet 10/100 Mbps
* USB Host
Control Panel
* Color TFT LCD with navigation button
* Power on/off button
* Calibration button
Power
Auto Switching 100-240VAC, 50-60Hz
Environment
* Operation temperature: 41°F to 104°F (5°C to 40°C)
* Storage temperature: -4°F to 122°F (-20°C to 50°C)
Humidity
* Operation: 30-85%, non-condensing.
* Storage: 10-90%, non-condensing.
Agency Approvals
CE(EMC), FCC Class A, CB, cUL, CCC
Dimension
* Length: 20.15” (512 mm)
* Height: 11.45” (291 mm)
* Width: 10.78” (274 mm)
Weight
33 lbs (15Kg) ,excluding consumables
Options & Accessories
* Cutter Module
* Label Dispenser + Internal Rewinder
* Parallel port adopter module (Centronic female 36-pin)
* Applicator Interface (1 input, 3 outputs, power 500mA @ 5V, for project base)
* External label roll holder for 10” (250 mm) O.D. label rolls
* External label rewinder
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
